| Max inflow | 50 l/min 13 gpm |
| Regulated flow | Vedi tabella See table |
| Maxiumum pressure | 350 bar 5000 psi |
| Installation torque | 40÷45 Nm 30÷34 lbf ft |
Performaces and calibrations are carried out by using hydraulic oil with 30 cSt viscosity at 50°C
Recommended viscosity 10 ÷ 420 cSt
Working temperature -20 ÷ +90 °C
Absolute filitration 25 μm
| Code | Regulated flow |
| 01 | 0÷2.6 gpm |
| 02 | 0÷5.3 gpm |
| 03 | 0÷9.2 gpm |
