| Max flow | 80 l/min 21 gpm |
| Max regulated flow | 2-50 l/min 0.5-13 gpm |
| Max pressure | 300 bar 4350 psi |
| Installation torque | 70 ÷ 80 Nm 52 ÷ 60 lbf ft |
Performaces and calibrations are carried out by using hydraulic oil with 30 cSt viscosity at 50°C
Recommended viscosity 10 ÷ 420 cSt
Working temperature -20 ÷ +90 °C
Absolute filitration 25 μm
