| Maximum flow | 30 l/min |
| Maximum pressure | 350 bar |
| Cracking pressure V1->V2 | 8 bar |
| Cracking pressure V2->V1 | 0.5 bar |
Performaces and calibrations are carried out by using hydraulic oil with 30 cSt viscosity at 50°C
Recommended viscosity 10 ÷ 420 cSt
Working temperature -20 ÷ +90 °C
Absolute filitration 25 μm
code
description
max. flow rate
max. pressure
threads
(ordering initials)
l/min
gpm
bar
psi
VB000037
VBDE38
30
7.93
350
5076
G3/8
VB000114
VBDE38 60 BAR
30
7.93
350
5076
G3/8
VB000186
VBDE38 12 BAR
30
7.93
350
5076
G3/8
