| Type |
V |
Max. pressure [bar] | Max. flow [l/min] | Cracking pressure [bar] |
| VBD-L-F-38 | 3/8"GAS | 350 | 35 | 3 |
| VBD-L-F-12 | 1/2"GAS | 350 | 50 | 2 |
| VBD-L-F-34 | 3/4"GAS | 250 | 80 | 2 |
| Pilot ratio | 4:1 |
Performance and calibrations are carried out by using hydraulic oil with 30 cSt a 50°C
Reccommended 10 ÷ 420 cSt
Working temperature -20 ÷ +90 °C
Absolute filitration 25 μm
code
description
max. flow rate
max. pressure
threads
(ordering initials)
l/min
gpm
bar
psi
VB000083
VBDLF38
35
9.25
350
5076
G3/8
VB000091
VBDLF38 OR SUL PISTONE
35
9.25
350
5076
G3/8
VB000093
VBDLF38A (ACCIAIO)
35
9.25
350
5076
G3/8
VB000100
VBDLF12
50
13.21
350
5076
G1/2
VB000120
VBDLF34
80
21.13
250
3626
G3/4
VB000125
VBDLF12 OR SUL PISTONE
50
13.21
350
5076
G1/2
VB000181
VBDLF12A (ACCIAIO)
50
13.21
350
5076
G1/2
VB000286
VBDLF38 R.P. 7:1 8 BAR
35
9.25
350
5076
G3/8"
VB000287
VBDLF12 R.P. 6:1 8 BAR
50
13.21
350
5076
G1/2"
