| Type | V C | Max pressure [l/min] | Max flow [l/min] |
| VBS-L-14 | 1/4" GAS | 350 | 20 |
| VBS-L-38 | 3/8" GAS | 350 | 35 |
| VBS-L-12 | 1/2" GAS | 350 | 50 |
| VBS-L-34 | 3/4" GAS | 250 | 80 |
| Cracking pressure |
3 bar 2 bar |
| Pilot ratio | 4:1 |
Performance and calibrations are carried out by using hydraulic oil with 30 cSt a 50°C
Reccommended 10 ÷ 420 cSt
Working temperature -20 ÷ +90 °C
Absolute filitration 25 μm
code
description
max. flow rate
max. pressure
threads
(ordering initials)
l/min
gpm
bar
psi
VB000016
VBSL14
20
5.28
350
5076
G1/4
VB000017
VBSL38
35
9.25
350
5076
G3/8
VB000018
VBSL12
50
13.21
350
5076
G1/2
VB000019
VBSL34
80
21.13
250
3626
G3/4
VB000049
VBSL14A (ACCIAIO)
20
5.28
350
5076
G1/4
VB000050
VBSL38A (ACCIAIO)
35
9.25
350
5076
G3/8
VB000051
VBSL12A (ACCIAIO)
50
13.21
350
5076
G1/2
VB000052
VBSL34A (ACCIAIO)
80
21.13
250
3626
G3/4
VB000088
VBSL1202 (3 BAR)
50
13.21
350
5076
G1/2
VB000092
VBSL38 R.P. 7:1
35
9.25
350
5076
G3/8
