PARKER
OVC-DE-FMP-SF-VC-12
Double effect overcentre valve with brake unclamping, flangeable to PARKER motors, series TE-TJ
| Maximum flow | 60 l/min |
| Maximum pressure | 350 bar |
| Standard pilot ratio | 4,25:1 |
| Pilot ratio upon request | 3:1 8:1 10:1 |
| Setting | The valve must be set at least 1.3 times maximum load induced pressure | ||
| Code | Standard setting bar (Q= 5l/min) |
Setting range bar |
Spring color |
| 01 | 100 | 20÷200 | White |
| 02 | 280 | 50÷350 | Black |
Ordering examples: OVC60C02Performaces and calibrations are carried out by using hydraulic oil with 30 cSt viscosity at 50°C
Recommended viscosity 10 ÷ 420 cSt
Working temperature -20 ÷ +90 °C
Absolute filitration 25 μm
code
description
max. flow rate
max. pressure
threads
(ordering initials)
l/min
gpm
bar
psi
OVC00628
OVCDEFMPSFVC1202
60
15.85
350
5076
G1/2
