| Maximum flow | 50 l/min 13.2 gpm |
| Maximum inlet pressure |
350 bar |
| Installation torque | 45÷50 Nm 33÷37 lbf ft |
| Setting | ||
| Code | Standard setting (Q= 5l/min) |
Adj. pressure range |
| 00 | 40 bar 580 psi |
5÷40 bar 72.5÷580 psi |
| 01 | 80 bar 1160 psi |
10÷100 bar 290÷1450 psi |
| 02 | 180 bar 2610 psi |
10÷250 bar 145÷3625 psi |
Performaces and calibrations are carried out by using hydraulic oil with 30 cSt viscosity at 50°C
Recommended viscosity 10 ÷ 420 cSt
Working temperature -20 ÷ +90 °C
Absolute filitration 25 μm
