VNR80-C

Check valve, cartridge type
VNR80-C
Download the PDF
CHECK VALVES
VNR80-C
Check valve, cartridge type
Maximum flow 80 l/min
Maximum pressure 300 bar
Cracking pressure 1 bar
3 bar
5 bar
Installation torque 65÷70 Nm

Performaces and calibrations are carried out by using hydraulic oil with 30 cSt viscosity at 50°C
Recommended viscosity 10 ÷ 420 cSt
Working temperature -20 ÷ +90 °C
Absolute filitration 25 μm

code
description
max. flow rate
max. pressure
cavities
3dfiles

(ordering initials)

l/min

gpm

bar

psi

VNR00004
VNR80C
80
21.13
300
4351
VNR00072
VNR80C 6 BAR
80
21.13
300
4351
VNR00097
VNR80C 1 BAR
80
21.13
350
5076
VNR00098
VNR80C 0.5 BAR
80
21.13
350
5076
