DFR-VLP5

Divisore di flusso CON VLP5C incrociate
DFR-VLP5
Scarica il PDF
DIVISORI
DFR-VLP5
Divisore di flusso CON VLP5C incrociate
Codice DFR-VLP5
Q (l/min)
01 3÷6
02 7÷12
03 13÷25
MAXIMUM PRESSURE

300 bar

Performaces and calibrations are carried out by using hydraulic oil with 30 cSt viscosity at 50°C
Recommended viscosity 10 ÷ 420 cSt
Working temperature -20 ÷ +90 °C
Absolute filitration 25 μm
