| Modello | A, B | Portata massima | Pressione massima |
| V2M-14 | 1/4"GAS | 25 l/min | 350 bar |
| V2M-38 | 3/8"GAS | 40 l/min | 350 bar |
Performaces and calibrations are carried out by using hydraulic oil with 30 cSt viscosity at 50°C
Recommended viscosity 10 ÷ 420 cSt
Working temperature -20 ÷ +90 °C
Absolute filitration 25 μm
codice
descrizione
portata max
pressione max
filettature
3dfiles
(sigla di ordinazione)
l/min
gpm
bar
psi
VFC00013
V2M14NA
25
6.60
350
5076
G1/4
VFC00014
V2M14NC
25
6.60
350
5076
G1/4
VFC00033
V2M14NC OR VITON
25
6.60
350
5076
G1/4
VFC00034
V2MCNC OR VITON
25
6.60
350
5076
G1/4
