ПРОСТОГО ДЕЙСТВИЯ
VBS-SF-M / VBS-SP-M
Single effect, pilot operated check valve, ball or poppet type
| Type |
Pilot ratio |
Max. pressure [bar] | Max. flow [l/min] | Cracking pressure [bar] |
| VBS-14-SF | 4:1 | 350 | 20 | 1.5 |
| VBS-38-SF | 4:1 | 350 | 35 | 3 |
| VBS-14-SP | 4:1 | 350 | 20 | 1.5 |
| VBS-38-SP | 4:1 | 350 | 35 | 3 |
Performance and calibrations are carried out by using hydraulic oil with 30 cSt a 50°C
Reccommended 10 ÷ 420 cSt
Рабочая температура -20 ÷ +90 °C
Полная фильтрация 25 μm
